4-Channel Mini Audio Mixer Sound Card Professional Console Computer Input 48v Power USB Computer

Analog mixer combined with digital sound card.
4 channel mixer.
2 pcs microphone / 2 line input (2 channel signal input and 2 channel stereo).Hiqh-resolution,dual-track recording and playback.Built-in high-speed ARM chip with unique processing technologies such as low noise,voice change, pitch change, reverberation, delay, electric sound effects, etc.
Multiple input/output combined interfaces, multiple recording methods are availableHighly usable power input mode and switch-mode 48V phantom power.
High-quality EQ and high-pass filter.
Multiple recording groups are optional and dual monitor mode is optional.
Flexible LOOPBACK function, perfect for recording and webcast.
Using LXR combination microphone input interface.
Visual recording status on the electric level, convenient for flexible adjustment at any time
1.FR:Input to STEREO OUT 0.5dB/-1.0dB(20Hz-20kHz), Test rated output level @1kHz, GAINknob: Mid
2.Input:MiC*2、2RCA、PC、2LINE、USB、BT、3.5MINI
3.Output: STEREO OUT:2, PHONES: 3.5MINI MAINPH OUT:1,3.5MINI LOOPBACK OUTPUT
4Bus:Stereo :1
5.Input channel functions:HPF(Mono):80 Hz,12dB/Octave(CH3.4)
6EQHIGH GAIN:+15dB/-15dB
Frequency response:10kHz Ramp frequency
EQLOW GAIN:+15dB/-15dB
Frequency response:100Hz Ramp frequency
PEAK LED:LED turns on when the signal after EQ reaches 3dB below distortion
7Level indicate the MAIN STETREO LEVEL knob, the green light will be on when the signal afterMAIN LEVE reaches 0dB, the red light will be clipped when the signal reaches 0dB below thedistortion, and the LED will turn on and light up.
8.Input and output level :MIC(-60dB) LINE ONPUT(-40dB)
